The SZBL-10H charging terminal comes with 10 outlets, 220V power supply, and a maximum power of 1500W per port. It supports independent 2G/4G communication, works in a wide temperature range of -40~85℃, is V0 flame retardant, and has a mechanical life of over 5000 uses. It has basic IP50 protection, and with a waterproof casing, it can reach IP65. It can be wall-mounted or floor-standing, offers multiple safety protections, and supports scheduled and metered charging with auto-stop when fully charged.
Product Introduction
Attribute | Parameter |
Model | SZBL-10H |
Product Size | 230 × 82.8 × 350 mm |
Communication | Independent 2G/4G + socket |
Number of Sockets | 10 |
Operating Voltage | AC 220 V |
Max. Power per Port | 1,500 W |
Operating Temperature | -40 to 85℃ |
Flame-Retardant Rating | V0 |
Mechanical Life | >5,000 cycles |
Water/Dust Rating | IP50 (up to IP65 with waterproof enclosure) |
Installation | Wall-mounted or floor-standing |
Safety Protection | Leakage, overload, overvoltage, overcharge |
Charging Modes | Time, energy, power, auto stop when full |
